CSA Grinding machines

CHESTER CSA SERIES HEAVY DUTY BENCH GRINDERS

Heavy duty grinders, ideal for workshops.

Please contact us for more info.

Categories: Bench & Pedestal Grinders, Grinding Machines Tags: CS SERIES, GRINDING MACHINES, machines

Description

Looking for a complete grinding center with unlimited power and unlimited life? Our CSA Series is the answer! The strongest bench grinder for industrial usage.

Comes with 10 year warranty.

Model	CSA-1	CSA-2	CSA-3	CSA-4	CSA-5
Motor	0.37kW (0.5hp)	0.750kW (1hp)	1.1kW (1.5hp)	1.5kW (2hp)	1.8kW (2.5hp)
Speed	2800rpm	2800rpm	1400rpm	1400rpm	1400rpm
Wheel Size	150 x 20 x 16mm	200 x 25 x 20mm	250 x 30 x 25mm	250 x 35 x 25mm	300 x 35 x 25mm
Weight	48kg	64kg	91kg	91kg	124kg
Dimensions	800 x 710 x 1300mm	800 x 710 x 1300mm	800 x 710 x 1300mm	800 x 710 x 1300mm	800 x 1200 x 1300mm

Model	CSA-6	CSA-7	CSA-8	CSA-9	CSA-10
Motor	2.2kW (3hp)	3.7kW (5hp)	4.4kW (6hp)	0.375kW (0.5hp)	0.75kW (1hp)
Speed	1400rpm	1400rpm	1400rpm	2800rpm	2800rpm
Wheel Size	300 x 40 x 30mm	400 x 50 x 40mm	400 x 50 x 40mm	150 x 20 x 16mm	200 x 25 x 20mm
Weight	124kg	246kg	246kg	49kg	65kg
Dimensions	800 x 1200 x 1300mm	800 x 1200 x 1300mm	800 x 1200 x 1300mm	800 x 710 x 1300mm	800 x 710 x 1300mm

Click the links below to download the specific documents.

CSA-Series-1.pdf
