Description
A high performance metal lathe that’s ideal for machining.
• Hardened and Ground Bedways
• Independent Lead Screw and Feed Rod
• Taper Roller Bearing Headstock
• Tool Cabinet
• 3 Axis DRO
• LED Work Light
| Centre Height | 165mm |
| Swing over Bed | 330mm |
| Distance Between Centres | 1000mm |
| Swing over Cross Slide | 205mm |
| Cross Slide Travel | 185mm |
| Top Slide Travel | 85mm |
| Bed | |
| Width | 195mm |
| Headstock | |
| Spindle Nose | D1-4 Camlock |
| Spindle Bore | 38mm |
| Spindle Taper | MT5 |
| Number of Spindle Speed Ranges | 12 steps |
| Range of Spindle Speeds | 75-2000r/min |
| Swivel Angle of Toolpost | +/-60° |
| Tailstock | |
| Quill Diameter | 32mm |
| Quill Travel | 85mm |
| Quill Internal Taper | MT3 |
| Feeds Range and Gearbox | |
| Longitudinal Feeds | 0.05-0.50mm/r (15steps) |
| Cross Feeds | 0.02-0.20mm/r (15steps) |
| Metric Threads | 0.25-5.0mm (18steps) |
| Imperial Threads | 6-96tpi (13steps) |
| Leadscrew Pitch | 3mm |
| Motors | |
| Main Motor | 1.5kW (2hp) |
| Coolant Pump Motor | 0.04kW (0.05hp) |
| Weight And Dimensions | |
| Dimensions | 1730x765x635mm |
| Net Weight | 330kg (without stand) |
| Power Supply | 240V single Phase |
Standard Accessories
• 3 Jaw Chuck 160mm
• 4 Jaw Chuck 160mm
• 3 Axis Industrial Digital Read Out
• LED Machine Lamp
• Chuck Guard
• Toolpost Guard
• Leadscrew Guard
• Fixed Steady
• Travelling Steady
• Full Length Rear Splash Guard
• Coolant System
• 4 Way Tool Post
• Thread Chasing Dial
• Single Position Micrometer Bed Stop
• Reducing Sleeve
• Steel Centre
• Tool Box
• Manual
Optional Accessories
• Vertical Milling Head
• Live Centre
• Indexable Lathe Tools
• Face Plate
• Drill Chuck and Arbor
• Machine Mounts
• 5C Collets and Chuck
