Description
| Drilling Mild Steel | 25mm |
| Drilling Cast Iron | 28mm |
| Tapping Mild Steel | M18 |
| Tapping Cast Iron | M20 |
| Spindle Taper | MT3 |
| Distance from Spindle to Column | 240mm |
| Distance from Spindle to Base(min/max) | 80-650mm |
| Rotation of Table along with column | ±180° |
| Vertical Travel of Drilling Head | 470mm |
| Maximum Spindle Traverse(hand/power) | 110mm |
| Number of Spindle Speeds | 6 |
| Range of Spindle Speeds | 125-2825rpm |
| Base Size Overall | 545X400X100mm |
| Base Working Surface | 310x320mm |
| Number and Size of T Slots on Base | 2/12mm |
| Distance between T Slots | 160mm |
| Column Diameter | 100mm |
| Main Motor Power | 0.75kw(1hp) |
| Overall Height | 1425mm |
| Footprint(LxW) | 700x460mm |
| Net Weight< | 220kg |
Image shown is of a typical GB25 Drill.
12 months parts warranty.
You are welcome to visit our factory & showroom in Burntwood, WS7 3GN to view this machine.
