Universal Dividing Heads BS-2

£1,684.62

Description

Stock-code Model A B H h a b g Taper of centre Weight
HOM-BS-2 BS-2 365 272 236 132.7 213 134 16 B&S No.10 73kg

Tail Stock for Universal Dividing Head BS-2

No Model A1 a1 b1 g1a H1 Centre Height (h2)
D-07 BS-2 194 177 125 16 147 Max: 138      Min: 115



Numbers of hole Plate A 15 16 17 18 19 20
Plate B 21 23 27 29 31 33
Plate C 37 39 41 43 47 49

FEATURES

This Universal Dividing Head has been designed to carry out all types of gear cutting.  Precision dividing and spiral work (except Type BS-0 and BS-1) with greater precision and efficiency than has been possible before.  The centre face can be tilted from a horizontal position of 90° down to –10° from vertical, and inclinations can be read off a scale graduated in ºrees.  The ratio of worm to gear is 1:40.

Additional information

Weight 73 kg
