- Pendant Control.
- High precision Table and Spindle.
- Newall DP700 Digital Readout.
- Ergonomic Design.
| Model | HB130/2 |
| Spindle |
|
| Spindle Diameter | 130mm |
| Spindle Taper | Metric 80(Optional ISO7:24No50 |
| Max. Spindle Torque | 3136N.m |
| Max. Spindle Thrust | 31360N |
| Number of Spindle Speed | 24 |
| Range of Spindle Speed | 4-800rpm |
| Power of Main Motor | 15kw |
| Facing Head |
|
| Max. Facing Head Torque | 4900N.m |
| Facing Head Diameter | 750mm |
| Range of Facing Head Speed | 2.5-125mm |
| Number of Facing Head Speed | 18 |
| Table |
|
| Table Working Surface (L × W) | 1800x1600mm |
| Max. Permissible Load on Table | 10000kg |
| T-Slot | 28mm |
| Number of T-Slot | 9 |
| Work Range |
|
| X-axis travel (cross) | 2000mm |
| Y-axis travel (vertical) | 1800mm |
| Z-axis travel w/o tailstock (longitudinal) | 2000mm |
| Z-axis travel with tailstock (longitudinal) | 1500mm |
| W-Axis Travel (Spindle Travel) | 900mm |
| U-Axis Travel (Facing Slide Travel) | 250mm |
| B-Axis Worktable Rotary | 360 (4×90)mm |
| Distance between Spindle Axis and Table Surface | 0-1800mm |
| Feed Range Of Revolution |
|
| Rapid Travel (X/Y/Z/W) | 2500mm |
| Range of Axes Speed per Spindle Revolution (X/Y/Z/W) | 0.05-8/0.01-2mm |
| Precision |
|
| Measurement System Reading Precision (X/Y/Z) | 0.005 |
| B-Axis Reading Precision (Optional) | 0.001 |
| Machine Dimensions (L × W x H) | 7030x4665x3800mm |
| Net Weight | 29300kg |
Standard Accessories
• Face Plate
• DP700 DRO from Newall(UK)
• Rear Column
• Concentrated Control Panel
• Lubrication System
• Tool Kits
• Foundation Books
• Manual Books
Optional Accessories
• Spindle Taper: ISO 7:24 #50
• Z-axis DRO
• B-axis DRO
• Angle Table 1000×630×800mm
• Changing Gears (Used for Thread-Cutting Tool Holder)
• Thread-Cutting Tool Holder for Spindle
• Toolholders for Facing Head
• Universal Boring Head (Metric #80 or Iso 7:24 #50)
• Boring Tools (12Pcs)
• Reducing Sleeve(80#~7:24)
• Boring Tool Bars
