Centralised operation button panel.
Table with manual 4 jaw chuck with chuck jaws.
High precision bearings in table speed change gearbox.
Centralised lubrication system.
Work lamps
• Hydrostatic working table with constant flow hydraulic power supply
• Hydraulic balancing mechanism on rams for high precision cutting
| Table Diameter | 1400mm |
| Max.Turning Diameter | 1600mm |
| Max.Working Height | 1000/1200/1400/1600mm |
| Max.Weight of Workpiece | 5000kg |
| Speed Range of Table | 5-160r/min |
| Speed-step of Table | 16 |
| Feed Range | 0.8-86r/min |
| Feed Steps | 12 |
| Horizontal Travel of Rail Head | 915mm |
| Vertical Travel of Rail Head | 800mm |
| Horizontal Travel of Side Head | 650mm |
| Vertical Travel of Side Head | 1000mm |
| Travel of Cross Beam | 850/1050/1250/1450mm |
| Moving Degree Limit of Rail Head | ±30° |
| Size of Tool Bar (L×W) | 30×40mm |
| Power of Main Motor | 30kw(40.2hp) |
| Power of Feed Motor | 1.3/1.8kw(1.7/2.4hp) |
| Net Weight of Machine | 12700kg |
| Overall Dimensions (L×W×H) | 2662×2800×3550mm |
Standard Accessories
• Tool post
• 2 Axis DRO
Optional Accessories
• Side Turret
• DRO for Side Turret
• 4 Step Gearbox
