Kitchen & Walker GP40S Square Column Drill
Please contact our Sales Team for pricing: [email protected]. Or Call us Today: 01543 448940
Drilling Capacity (Steel): 40mm
Drilling Machines
Our GP40S drill is ideal for machining. Complete with speed control and lever.
| Model | GP40S |
| Drilling Capacity Mild Steel | 40mm |
| Drilling Capacity Cast Iron | 50mm |
| Tapping Capacity Mild Steel | M24 |
| Tapping Capacity Cast Iron | M27 |
| Spindle Taper | MT4 |
| Distance from Spindle to Column | 335mm |
| Distance from Spindle to Table(min/max) | 0-830mm |
| Vertical Travel of Drilling Head | 200mm |
| Vertical Travel of Table | Max.300mm |
| Table Size | 560 x 480mm |
| Number and size of T slots on Table | 3 , 32 x 30 x 18mm |
| Distance between T Slots | 150mm |
| Maximum Spindle Traverse(hand/power) | 250mm |
| Number of Spindle Speeds | 12 |
| Range of Spindle Speeds | 31.5-1400r/min |
| Number of Feed Rates | 9 |
| Power Feed Rates | 0.056-1.80mm/rev |
| Base Size Overall | 1030 x 670 x 160mm |
| Base Working Surface | 510 x 495mm |
| Number and Size of T Slots on Base | 2/32 x 30 x 18mm |
| Distance between T Slots | 330mm |
| Column Diameter | 435 x 460 x 1905mm |
| Main Motor Power | 3kW(4hp) |
| Coolant Pump Motor | 0.09kW(0.1hp) |
| Overall Height | 2535mm |
| Footprint(LxW) | 1030 x 670mm |
| Net Weight | 1190kg |
Standard Accessories
• Drill Chuck
• Taper Sleeve
• Arbor
• Drift
• Wrench
Optional Accessories
• Machine Vice
• Clamp Kit
• Taper Shank Drill Set
