CHESTER VF1300 HIGH SPEED ULTRA HIGH PERFORMANCE CNC MACHINING CENTRE

CHESTER VF1300 HIGH SPEED ULTRA HIGH PERFORMANCE CNC MACHINING CENTRE

Please contact our Sales Team for pricing: [email protected]. Or Call us Today: 01543 448940
Table Size: 1500 x 650mm
Spindle Taper: SK40 / BT40 / CAT40
CNC Machining Centres
Contact Us

Please contact our team for a custom quote and competitive pricing

Add to cart
Add to wishlist
Price
£ 0.00 £ 0.00

The Chester VF1300 High Speed Ultra High Performance CNC Machining Centres advanced machine design has a reinforced body structure through FEM analysis and extra wide machine column and base design to ensure the high rigidity during high speed movement. The VF series CNC Machines offers superb cutting performance and reduced vibration to meet the highest machining demands.

Our CNC Machining Centres offer:

  • Ultra high performance and high rigidity for Precision mould making
  • High spindle torque
  • BBT spindle for higher rigidity
  • Roller type linear guideway
  • Direct drive provides backlash free, best accuracy, reliability and stability
  • Extra wide machine column and base design ensures the high rigidity during high speed movement
  • Motor seat cooling circuit
  • Oil cooled ballscrew (option)
  • Linear scales (option)

Technical SpecificationsVF1300
Table
Table size1500 x 650mm
T-slot (width x number x distance)
18 x 6 x 100mm
Max. load1200kgs
Travel
X/Y/Z Travel1300 / 650 / 600mm
Spindle nose to table
130 - 830mm
Spindle centre to column802mm
Spindle

Spindle Taper
SK40 / BT40 / CAT40
Spindle servo motor
20 / 53 Siemens, 15 / 30 Fanuc kW
Spindle Speed
1500 Siemens rpm min-1, 12000rpm min-1 Fanuc
Spindle (option 1)
HSK A63, 20000rpm
Motor power / torque
20/24kW; 32/42Nm
Spindle (option 2 )
HSK A63, 20000rpm
Motor power/torque
25/28kW; 87/105Nm
Feed

Rapid Feed X/Y/XZ
24m/min
Cutting feed
1-12.000mm/min
Tool changer

Number of tools
24 pcs
Max. tool length
300mm
Max. tool diameter
78 (125)mm
Max. tool weight
8kg
Accuracy (VDI 3441)

Positioning accuracy (without linear encoder)
0.012mm / Full Travel
Positioning repeatability (without linear encoder)
0.008mm / Full Travel
Positioning accuracy (with linear encoder)
0.008mm / Full Travel
Positioning repeatability (with linear encoder)
0.006mm / Full Travel
Dimensions & weight
Dimensions4025 x 3693 x 3250mm
Weight8500kgs

STANDARD ACCESSORIES

• Fully enclosed splash guard

• Direct drive spindle 15000 rpm

• 24 pockets arm tool changer

• Two screw type and one chain type

• Spindle cooling system

• Air-conditioned electrical cabinet

• Motor seat cooling circuit

• Rigid tapping

• Ethernet, CF card and USB interface

• Automatic lubrication system

• Coolant system

• LED working lamp

• End of program light

• Electronic handwheel (MPG)

• Tool box

• Leveling bolts and blocks

• Coolant gun

• Air gun

• Air blast during cutting

• User Manual



OPTIONAL ACCESSORIES

• Direct drive spindle 6000 rpm, BBT50

• Motor spindle 20000 rpm, HSK A63

• CTS coolant through spindle + ATS

• Oil cooled ballscrew

• Oil skimmer

• Linear scales

• 4th axis

• 4/5th axis

• Workpiece probe

• Tool probe
