CHESTER 732 SUPER MILLING MACHINE

45° Head tilt left and right.

Inverter drive for optimal speed control.

Description

Max. Drilling Capacity (iron/steel)	30/25mm
Max. Milling Capacity (face milling)	76mm
Max. Milling Capacity (end milling)	20mm
Work Table Size	800x178mm
Cross/longitudinal Travel Work Table	200mm/440mm
Spindle Taper	MT3/R8
Spindle Travel	80mm
Spindle Speed (9 steps)	50HZ:190-2100rpm
Max. Distance Spindle to Table	545mm
Head tilt left right	+/-45°
Spindle Swivel	360°
Motor Power	1.5kW
Available Power Supply	240V Single Phase
Machine Dimensions	1300x1010x1830mm
Net Weight	480kg
