Description
| Model | Lux B Mill/Drill |
| Max. Drilling Capacity (iron/steel) | 30mm |
| Max. End Milling Capacity | 32mm |
| Spindle Taper | MT3 |
| Dimension of Base | 670 x 470mm (water tank) |
| Spindle speed (single phase machine) | 75-1600rpm (6 steps) |
| Spindle speed (3 phase machine) | 75-3200rpm (12 steps) |
| Work table size | 730 x 210mm |
| Work table travel | 490mm (X) 180mm (Y) |
| Spindle travel | 120mm |
| Diameter of column | 115mm |
| Max. distance spindle nose to work table | 610mm |
| Max. distance spindle nose to table | 1180mm |
| Motor Power | 1.5kW |
| Machine Dimensions | 1075 x 745 x 1795mm |
| Net Weight | 350kg |
| Power supply | 240v Single phase or 400v 3 phase |
Image shown is of a typical Lux B Drill.
12 months parts warranty.
You are welcome to visit our factory & showroom in Burntwood, WS7 3GN to view this machine.
