Super Lux B Milling Machine | Chester Machine Tools

Description

Our Super Lux B is ideal for workshops, a precision machine with geared head and power feed.

Features:

Fully equipped Heavy Duty gear head machine
Precision headstock gears for quiet operation
Robust square column casting ensures optimal rigidity
Equipped with longitudinal power feed for convenience
Comes with Auto Tapping function
Motorized head eliminates manual cranking for elevation and descent adjustments
Powered elevation along machined dovetail slideways
Spindle supported by roller bearings for durability
Rack and pinion system for drilling feed
Spindle depth lock feature
Includes an interlock chuck guard for safety
Table locks provided for X and Y axes
Two-axis digital readout for precise measurement for table movement
Digital depth gauge accurately measures spindle travel to provide accurate measurement for 3rd axis

Max. drilling capacity (iron/steel)	Ø30mm
Max. milling capacity (face milling)	Ø80mm
Max. milling capacity (end milling)	Ø32mm
Max. distance spindle to table	460mm
Z-axis travel	350mm
Sleeve travel	120mm
Spindle taper	MT3
Spindle speed (single phase machine)	75-1600rpm, 6steps
Spindle speed (3 phase machine)	75-3200rpm (12 steps)
Max. swing of headstock	+/-45°
Work table size	800x240mm
T slot size	14mm
Working table longitudinal travel	560mm
Working table transverse travel	190mm
Motor power	1.5kW
Available Power Supply	240V single Phase / 400V 3 Phase
Machine Dimensions	1147x928x1320mm
Net Weight	315kg

Standard Accessories

• MT3 Spindle

• Interlocked Table Guard

• Drawbar

• Drill Chuck with Taper Shank

• LED Work Light

• Auto Tapping

• Electronic Depth Display Provides precise 3rd Axis Measurement

• 2 Axis Precision Digital Readout System

• Tool Box

• Manual

Optional Accessories

• R8 Spindle

• MT4 Spindle

• ISO30 Spindle

• X Axis Power Feed

• ER Collet Chuck Set

• Milling Vice K100/V100

• Clamping Kit

• Boring Head Set

• Reducing Sleeves

• Angle Milling Table

• Rotary Table

• Indexing Plates Set for Rotary Table

• Milling Cutter Set

• Drill Set

• Face Milling Cutter

• Stud Milling Arbor
