D32 Series Pedestal Drill | Chester Machine Tools

Description

Our D32 Pedestal Drill is ideal for workshops, with 45° tilting table and 32mm drilling capacity.

Drill	D32
Drilling Capacity (Mild Steel)	32mm
Drilling Capacity (Cast Iron)	32mm
Tapping Capacity (Mild Steel)	MT4
Tapping Capacity (Cast Iron)	MT4
Spindle Taper	MT4
Distance from Spindle to Column	254mm
Distance from Spindle to Table(min/max)	190-680mm
Distance from Spindle to Base(min/max)	1200mm
Rotation of Table along with column	360°
Tilting Angle of Table	45°-45°
Vertical Travel of Table	490mm
Table Size	475 x 425mm
Number and size of T slots on Table	3/16 x 350mm
Distance between T Slots	110mm
Maximum Spindle Traverse(hand/power)	120mm
Number of Spindle Speeds	12
Range of Spindle Speeds	150-2700rpm
Number of Feed Rates	1 or 3
Power Feed Rates	50hz
Base Size Overall	580 x 450mm
Base Working Surface	410 x 330mm
Number and Size of T Slots on Base	2/16 x 330mm
Distance between T Slots	246mm
Column Diameter	92mm
Main Motor Power	1.5kW(2.01hp)
Overall Height	1710
Net Weight	138kg
Machine Dimensions	580 x 450 x 1710mm
