CHESTER V13L – V15L ALPHA CNC MACHINING CENTRES

Advanced manufacturing CNC machines that can perform a variety of machining operations, with high performance and high rigidity these machines are suitable for mould making.

Please contact us for more info.

Description

Cast Iron is Tempered for Stress Relief to Ensure Structural Stability without Deformation. C3 Class Ballscrews Ensure the Highest Accuracy and Durability. Pretension on All Axis Minimizes Thermal Distortion.

MODEL V13L V15L
Table
Table Size 1400×600mm 1700×600mm
T Slot (Width×Number×Distance) 18×5×100mm 18×5×100mm
Max.Load 1000kg 1200kg
Travel
X/Y/Z Travel 1300/760/670mm 1500/760/670mm
Spindle Nose to Table  80-750mm 80-750mm
Spindle Centre to Column 797mm 797mm
Spindle
Spindle Type and Diameter BT40 BT40
Spindle Servo Motor Siemens 15/38kw(20.4/51.68hp) 15/38kw(20.4/51.68hp)
Spindle Servo Motor Fanuc 11/15kw(14.96/20.4hp) 11/15kw(14.96/20.4hp)
Spindle Speed 10000rpm 10000rpm
Feed
Rapid Feed X/Y/Z 24m/min 24m/min
Cutting Speed 1-12000mm/min 1-12000mm/min
Tool Changer
Tool Number  24 24
Tool Length 300mm 300mm
Max.Tool Diam. (Without Adjacent Tool) 78(120)mm 78(120)mm
Max.Tool Weight 8kg 8kg
Accuracy
VDI 3441(Full Travel) Positioning accuracy 0.012;Positioning repeatability 0.008 Positioning accuracy 0.015;Positioning repeatability 0.008
Dimension & Weight
Dimension  3700x2640x3100mm 3700x2640x3100 mm
Weight  8000kg 8500kg

STANDARD ACCESSORIES

• Siemens/Fanuc Controller

• Fully Enclosed Splash Guard

• Belt Drive Spindle 10000rpm

• 24 Pockets Arm Tool Changer

• Air Condition for Electrical Cabinet

• Rigid Tapping

• Ethernet CF Card and Usb Interface

• Automatic Lubrication System

• Coolant System

• Oil Separation

• Led Working Lamp

• End of Program Light

• Electronic Handwheel(MPG)

• Spindle Cooling System

• Tool Box

• Leveling Bolts and Blocks

• Coolant Gun

• Air Gun

• Chip Flushing System

• Operation Manual



OPTIONAL ACCESSORIES

• 30 Pockets Arm Tool Changer

• BT50 16 Pockets Arm Tool Changer

• Spindle Speed 12000rpm Direct Drive

• Coolant Through Spindle

• Chain Type Chip Conveyor

• Workpiece Probe

• Tool Probe

• Oil Mist Collector

• 3D Simulation (Siemens)

• Manual Guide Oi/I (Fanuc Type 5/1)

• 4th and 5th Axis

• Heidenhain Controller

• Lehmann Switzerland 4/5 Axis
